型号 MODEL |
最大弯管直径 Maximum bend diameter |
最大模弯半径(可定制) Maximum mold bending radius (customizable) |
最大有效送料行程(可定制) Maximum effective feeding stroke (customizable) |
最大弯曲角度 Maximum bending Angle |
弯曲精度 Bending accuracy | ||
|
Y轴 Y axis |
B轴 B axis |
C轴 C axis | |||||
|
CNC15 |
15mm |
75mm |
1500mm |
190° |
±0.05mm |
±0.05° |
±0.01° |
|
CNC25 |
25mm |
100mm |
1700mm | ||||
|
CNC30 |
30mm |
150mm |
2800mm |
190° |
±0.05mm |
±0.05° |
±0.05° |
|
CNC38 |
38mm |
190mm |
2800mm | ||||
|
CNC50 |
50mm |
250mm |
3200mm | ||||
|
CNC65 |
65mm |
298mm |
3800mm | ||||
|
CNC80 |
80mm |
360mm |
4000mm | ||||
|
CNC90 |
90mm |
400mm |
4000mm | ||||
|
CNC100 |
100mm |
450mm |
4000mm | ||||
|
CNC115 |
115mm |
500mm |
5000mm | ||||
|
CNC130 |
130mm |
500mm |
5000mm | ||||
|
CNC139 |
139mm |
500mm |
5000mm | ||||
|
CNC160 |
160mm |
640mm |
5000mm |
185° |
±0.05mm |
±0.05° |
±0.05° |
|
CNC189 |
189mm |
850mm |
6000mm | ||||
|
CNC220 |
220mm |
990mm |
6000mm | ||||
由于公司不断研发、更新、参数时有变化，具体详细参数请向合泰公司索取，特殊规格可定制。
Due to the company's continuous research and development, updating, and parameters are constanty changing, please ask Hetai for specic detaled parameters, and special specifications can be customized.
